Impact Sands Making Machine

Short Description:

The output particle size is diamond-shaped, and the alloy cutter head is wear resistant and durable with low maintenance cost.

INQUIRY

General Description

Applicable Scope

It is widely used in medium and fine crushing (making sand) of various hard and brittle materials such as various rocks, abrasives, refractory materials, cement clinker, quartz stone, iron ore, concrete aggregate etc. It is especially suitable for sand for construction and gravel for road construction.

Technical Specifications

Model	Max Feed Size (mm)	Max Throughput (t/h)	Capacity (t/h)	Power (kw)
XS7524	40	350	55-95	200
XS8024	40	400	70-120	250
XS9024	45	450	95-160	315
XS9026	45	500	120-180	400
